WFLY ET12 Detailed Manual

WFLY ET12 is a high-performance 2.4GHz two-way RC radio system designed for RC cars, boats, drones, helicopters, robots and model aircraft. It features stable signal, easy operation, touch color display and reliable telemetry, making it the ideal choice for RC enthusiasts and professionals.

Product Features

• 2.4GHz two-way transmission for stable and reliable control

• 3.5inch touch color display (480*320) with clear interface

• Support voice broadcast and real-time status prompt

• Support 180/270° servo and relay flight function

• Wireless model data copy and one-key settings synchronization

• Wide voltage design (3.5V-13V) for strong compatibility

• Support online upgrade for continuous function optimization

Transmitter Specifications (ET12)

• Type: ET12

• Channel: 12 channels

• Voltage: 3.5V-13V (1S-3S Lithium battery)

• Working Current: 260-400mA

• Application: Helicopter, Airplane, Multi-rotors, Vehicle, Ship

• Resolution: Full Channel 4096

• Band: 2.4GHz (Bidirectional)

• Model Storage: 30 models

• Programming: 5 Groups Mixed Control

• Language: Chinese, English

• Upgrading: USB online upgrade

• Display: 3.5inch touch, 480*320, color display

• Voice: Support voice broadcast

• Relay light: Available

• 180/270° Servo: Available

• Wireless signal copy: model data

Receiver Specifications (RF209S)

• Type: RF209S

• Band: 2.4GHz

• Voltage: 3.5V-13V

• Working Current: 95mA

• Application: Helicopter, Airplane, Multicopter, Vehicle, Ship, Robot

• Resolution: 4096

• PWM: 9 channels

• W.BUS: Compatible

• W.BUS2: Remote sensor input

• Two-way transmission: Available

• Lost-control protection: Available

• Online upgrading: Available

• Relay flight: Available

• 180/270° servo: Available

• Receiver port setting: Available

• External voltage detection: DC 0~96V

• Dimension: 47x14x25mm

• Weight: 12g

Standard Package Included

• 1 x WFLY ET12 Transmitter

• 1 x RF209S Receiver

• 1 x USB Charging Cable

• 1 x User Manual
