WFLY X9S Detailed Manual

WFLY X9S is a high-performance, multi-protocol remote control system designed for RC drones, cars, boats and aircraft models. It features stable signal transmission, long control distance, easy operation and rich expandability, providing users with safe and reliable remote control experience.

Key Features

• Multi-protocol compatible

• 3.5ms ultra-low latency

• Hall sensor gimbals for high precision

• Dual bearing protection for durable use

• 3.5-inch capacitive touch screen 480*320

• Supports cruise control, voice broadcast

• 40 model storage, 5 groups program mix

• 15W fast charging, Type-C port

• 2.4GHz FHSS & LORA two-way transmission

• Supports online USB upgrade

Transmitter Parameters

• Model Type: X9S

• Channel: 9 channels

• Latency: 3.5ms

• Hall Sensor Gimbals: Both trigger and runner with hall gimbals

• Bearing Numbers: Total 2 bearings with double protection

• Cruise Control: Support

• Working Voltage: 7.0V~8.4V

• Battery Support: 2S Lipo battery (battery compartment free inside)

• Charging: 15W fast charging, Type C 1S Lipo charging

• Working Current: 260~400mA

• Frequency Hopping: FHSS

• Modulation: LORA

• Resolution: 4096

• Frequency Band: 2.4GHz two-way transmission

• Transmission Power: ≤100mw

• Control Range: ＞600m (ideal environment)

• Temperature Range: -10℃—+60℃

• Simulator Interface: 3.5mm (PPM)
